Recently, I was working on a project, where we had to gather some information. Considering, this is going to be a minor task and executed only few times a day, server-less technology was the perfect choice for this scenario.
With more than 200 services in Azure, it is important to chose the best fit for this scenario. I could have easily built a ASP.NET MVC app with SQL Server back-end, but it will be a continuous running virtual machine and I’ll need to pay for it for entire month. Hence, for back-end, I decided to use Azure Table Storage as it will be a flat, single table structure. However, for front end, I was in a fix. Should I go for Azure Logic Apps or should I write a Azure Function? Considering there are already lot of articles like this and this and many more, I thought Azure Function will be a great choice. But then, I don’t want to touch JavaScript anymore :) So, I decided to take a different approach.
The Front-end: Microsoft Forms
Rather than writing HTML & JavaScript for this simple page, I thought about using technology which is designed for this purpose: Microsoft Forms. I created a Form and designed it to accept details from users (including people outside my organization).
The Back-end: Azure Table Storage
As mentioned earlier, for storing details, I’m using Azure Table Storage and this is Microsoft Azure Storage Explorer view of it. You can see I’m using Organization as PartitionKey and Email ID as RowKey. This will help to store and manage data easily.
The Compute: Azure Logic Apps
The last bit of this app is to get data from Microsoft Forms and pull it into Azure Table Storage for further utilization. Luckily, there is Azure Logic Apps connector available for Microsoft Forms. However, the trigger used here is available only if you sign in with Work/School or Office 365 account. I hope, this trigger will be made available for normal Microsoft account based Microsoft Forms as well.
Just save this Azure Logic App and it will execute whenever there will be a new entry in the Microsoft Form. You can see the details about this entry and execution details on Azure Portal.
Conclusion:
Azure Logic Apps with Microsoft Forms makes it super easy to build UI where we have to gather quick inputs from user. For example: registration forms, contact forms, invite for a party etc. Further, using Logic Apps, you can send automated emails, auto generate code for RSVP etc as and when required. This is perfect low-code (or shall I say no-code) solution
On 2nd April, Microsoft hosted Microsoft Innovation Summit in Kuala Lumpur, Malaysia & I got an opportunity to talk about Microsoft Azure Platform services which set up the foundation for AI services. For example, using Platform Services to host applications powered by Cognitive Services. This is just one scenario and I see endless possibilities. It was a pleasure to talk about and demo these services. Here, I’m sharing the slide deck used for this talk.
It can’t be just a coincidence that recently many of my friends expressed interest in monitoring how their teams are using their cloud subscription. And yet, all of them have a valid problem to worry about! Let’s talk about this problem, scenario, and solution in this last blog post of 2018 :)
Problem:
A subscription is shared with the team or each member has a separate subscription. Anyone can create any kind of resources (e.g. Virtual Machines, Storage Accounts, Network Security Groups, Web or Application Services, etc…). Even though there are policies and access restrictions which can be forced in Azure Portal, sometimes Administrators or Support engineers require (or literally they ask for) ‘God Mode’ with full access to play around, explore services or fix some things. In this case, monitoring these activities happened in ‘god mode’ & quick remediation or reversal is important before any damage happens.
Scenario:
Sometimes, developers often need to create resources to try out things. For example, they may want to create a Storage Account. Now, we want to enforce rules around Storage Account and make sure that the created Storage Account is accessible only via HTTPs protocol. Or let’s say Network Admin creates a Network Security Group (NSG) and in that case, the policy is to disable or enable specific ports or protocols (UDP/TCP/etc).
Solution:
I consider Azure Services as Lego blocks. You can mix and match and use them together as and when required. In this case, there are multiple ways to handle this scenario and possibly many more. There could be operations team managing this infrastructure using their custom tools. However, being a developer, I’ll focus on two solutions from a developer’s point of view. And I can see there are two easy solutions:
(1) Whenever a resource is created (or executed like Logic App trigger) or modified or deleted within a subscription, a record is maintained at subscription level and resource group level. This log can be further exported to different Azure services to take action. For example, it can be exported (or streamed) to Event Hub for event publishing.
(2) Using Azure Monitor set up a trigger to such records (create, update, delete resources) and take action (Notify by Email/Text, call Logic App, Functions, etc…)
Once these pipelines are set up, these services (Event Hub/Activity Log) will send data in JSON format which can be used to track down what has happened.
This file contains bidirectional Unicode text that may be interpreted or compiled differently than what appears below. To review, open the file in an editor that reveals hidden Unicode characters.
Learn more about bidirectional Unicode characters
This JSON has required information like resource id and resource type. In this case, I’m using Logic App to parse this JSON and accordingly call respective Azure Function which will take the action (by calling Azure Functions). I’m considering two scenarios here. (A) when new Storage Account is created and (B) when new Network Security Group is created/modified with Rules. But there can be many such scenarios!
Now according to the case (NSG/Storage Account), it will call the Azure Function. To modify the resources in subscription, I’m using Fluent APIs which makes life much easier. For example the following code creates a VM using Fluent APIs in US East Region within rgName provided:
This file contains bidirectional Unicode text that may be interpreted or compiled differently than what appears below. To review, open the file in an editor that reveals hidden Unicode characters.
Learn more about bidirectional Unicode characters
Using these Fluent APIs, let’s write Azure Function which will monitor newly created Storage Account and make sure that it is accessible only with HTTPs protocol.
This file contains bidirectional Unicode text that may be interpreted or compiled differently than what appears below. To review, open the file in an editor that reveals hidden Unicode characters.
Learn more about bidirectional Unicode characters
makes sure that Storage Account is accessible with HTTPs protocol only.
One last thing before executing this function or enabling Logic App, give permission to this Azure Function to modify resources. It can be done by creating and passing service principal or by using Managed Identity option. More details are here on this blog post. Managed Identity helps to avoid storing credentials in code.
Once this setup is complete, whenever Storage Account or Network Security Group is created, modified & updated, the Logic App will execute and call the respective Azure Function.
Conclusion
Using these various Azure Services, it is possible to monitor the subscription and perform actions on resources as per the rules. This makes governance easier. The sample and code used for Azure Functions in this blog post is available on GitHub here. Clone it and follow the steps there to deploy and run it in Azure subscription.
